OpenAPI to MCP

Standalone CLI for diagnosing, diffing, generating, running, and testing Node.js/TypeScript MCP servers from OpenAPI specifications.

Install first

Start with Installation, then confirm the binary is available:

openapi-to-mcp --help

Choose a workflow

Command Use it when Output
generate You want a reusable generated project on disk A TypeScript MCP server project
run You want one command to generate, build, and start a server locally A running MCP server
test-server You want to smoke-test a running server tools/list or tools/call output
doctor You want to assess spec readiness before generation A readiness report with warnings and errors
diff You want to compare MCP-surface changes between two specs A breaking/non-breaking change report

First commands to try

Generate a project:

openapi-to-mcp generate \
  --openapi-json ./openapi.yaml \
  --output-dir ./generated-server

Run directly from a spec:

openapi-to-mcp run \
  --openapi-json https://petstore.swagger.io/v2/swagger.json \
  --target-api-base-url https://petstore.swagger.io/v2

List tools from a running server:

openapi-to-mcp test-server \
  --transport streamable-http \
  --host 127.0.0.1 \
  --port 8080 \
  --mcp-endpoint /mcp \
  --list-tools

Start here

  1. Installation
  2. Getting Started
  3. generate
  4. run
  5. test-server
  6. doctor
  7. diff
  8. Auth and Environment
  9. mcpgen.yaml
  10. Generated Project
  11. Examples
  12. MCP Inspector
  13. Troubleshooting
  14. Local Workflows

Current capabilities

  • stdio and streamable-http transport targets
  • strict generation by default with generation_report.json
  • richer generated tool descriptions and input examples from spec metadata
  • optional grouped tool names with first-tag prefixes
  • optional request-scoped tool allowlists for streamable-http callers
  • optional redacted audit logs for request and response payloads
  • optional retry budgets and circuit breakers for safe upstream calls
  • reviewable performance presets built on top of the explicit runtime controls
  • generated auth env mapping for apiKey, bearer, OAuth2, and OpenID Connect
  • generated runtime controls for concurrency, queueing, timeout, bounded caching, rate limiting, retries, and circuit breakers
  • generated-server E2E coverage against a local mock API
  • CLI E2E coverage for generate, run, and test-server
  • version-aware GitHub Releases automation on master
  • repeatable generation policy with mcpgen.yaml
